AUS 59 - Port of Dampier (Northern Sheet) Nautical Chart

AUS 59 — Port of Dampier (Northern Sheet), WA Nautical Chart

For skippers, pilots, and coastal crews working Dampier’s northern fairways and berths

Tackle close-quarters pilotage around the Port of Dampier (North) with AUS 59. Large-scale harbour coverage at 1:10,000 on Universal Transverse Mercator (UTM)—ideal for plotting precise tracks, fixing positions, and verifying waypoints amid high-traffic Pilbara waters.

Why skippers choose this chart

• 🧭 Harbour-scale precision — 1:10,000 for approaches, swing basins, and berth alignments.

• 🚢 Traffic & hazards awareness — Supports safe shaping near channels, aids, and loading areas.

• 🛰️ UTM grid accuracy — Clean bearings and fixes for confident cross-checks.

• 📍 Exact bounds — All four limits listed for quick position checks (see below).

• 🗺️ Deck-ready materials — Soft-matte writeable face for correction/grease pencils.

• 🇦🇺 Printed in Australia — Colour-managed, hand-checked.

Coverage

• Main Chart — AUS 59: Australia North West Coast · Western Australia · Port of Dampier (Northern Sheet)

  • Scale: 1:10,000

  • Projection: Universal Transverse Mercator

  • Bounds: N 20°32.46′ S · S 20°38.52′ S · E 116°46.30′ E · W 116°42.55′ E

  • Publication: 13-Nov-1987 · Latest Edition: 21-Jun-2024

Premium materials & finishes

• Paper (120 gsm matte) — Crisp, flexible, chart-table friendly; ideal under nav-station glass.

• Laminated (soft-matte front / gloss back, edge-sealed) — Front is low-glare and writeable with chart-correction/grease pencils; gloss back adds rigidity. Wipes clean with a soft cloth.

We pair a soft-matte writeable face with a gloss reverse so you can annotate fixes, tides, ETAs and pilotage notes directly on the chart, then clean down between passages.

On-board & ashore use

• 🧭 Pilotage & berth approaches — Plot channels, clearing bearings, and contingency turns.

• 📒 Crew briefings — Clear layout for marks, hazards, and waypoint verification.

• 🛠️ Bridge/club display — Durable laminated option for training rooms and noticeboards.

Specifications

Important note (mariner’s guidance)

This product is ideal for planning, briefing, education, and display. For underway navigation, always carry and consult the latest official hydrographic chart or approved ECDIS and current Notices to Mariners. Port operations and local conditions may change.

Ready to work Dampier North with precision?

Select your finish above and add to cart. We’ll print locally, hand-check, and ship with care.
