AUS 41 — Plans in Western Australia (Sheet 1), WA Nautical Chart

For skippers, pilots, and coastal crews working the Kimberley iron-ore islands

Two large-scale harbour plans for Cockatoo Island and Koolan Island at 1:7,500 on Universal Transverse Mercator (UTM) — ideal for close-quarters pilotage, fixing, and timing tidal windows in Yampi Sound’s working waters.


Why skippers choose this chart

  • 🧭 Harbour-scale detail1:7,500 plans for precise route shaping around berths, wharves, and swinging basins.

  • 🚢 Traffic & hazards awareness — Supports safe transits near loading areas, reefs, and shoals.

  • 🛰️ UTM grid — Straightforward plotting and cross-checks for fixes and clearing bearings.

  • 📍 Exact bounds — All limits listed below for quick position checks.

  • 🗺️ Deck-ready materials — Soft-matte writeable laminate face for correction/grease pencils.

  • 🇦🇺 Printed in Australia — Colour-managed, hand-checked.


Coverage

  • Plan — AUS 41/1: Cockatoo Island

    • Scale: 1:7,500 · Projection: Universal Transverse Mercator

    • Bounds: N 16°05.60′ S · S 16°07.70′ S · E 123°38.40′ E · W 123°35.65′ E

    • Publication: 24-Oct-2008 · Latest Edition: 24-Oct-2008

  • Plan — AUS 41/2: Koolan Island

    • Scale: 1:7,500 · Projection: Universal Transverse Mercator

    • Bounds: N 16°07.60′ S · S 16°09.53′ S · E 123°46.10′ E · W 123°43.35′ E

    • Publication: 24-Oct-2008 · Latest Edition: 24-Oct-2008


Premium materials & finishes

  • Paper (120 gsm matte) — Crisp, flexible and chart-table friendly; ideal under nav-station glass.

  • Laminated (soft-matte front / gloss back, edge-sealed)Front is low-glare and writeable with chart-correction/grease pencils; gloss back adds rigidity. Wipes clean with a soft cloth.

Note: We use a soft-matte writeable face with a gloss reverse so you can annotate fixes, tides and ETAs directly on the chart, then clean down between passages.


On-board & ashore use

  • 🧭 Pilotage & berth approaches — Plot channels, clearing bearings, and contingency turns.

  • 📒 Crew briefings — Clear layout for hazards, marks, and waypoint verification.

  • 🛠️ Bridge/club display — Durable laminated option for training rooms and noticeboards.

  • 🎁 Gift for skippers — A practical Kimberley plans sheet for WA crews.


Specifications

Field Detail
Chart Number AUS 41 (Sheet 1)
Title Plans in Western Australia (Sheet 1) — Cockatoo Island; Koolan Island
Geographic Location Australia
Scale (main) 1:7,500 (two harbour plans)
Projection Universal Transverse Mercator (UTM)
North / South Limits 16°05.60′ S / 16°09.53′ S (combined envelope of the two plans)
East / West Limits 123°46.10′ E / 123°35.65′ E (combined envelope of the two plans)
Publication Date 24-Oct-2008
Latest Edition 24-Oct-2008
Sheet Size 770 mm (W) × 1100 mm (H)
Available Finishes Paper (120 gsm matte); Laminated (soft-matte writeable front, gloss back, edge-sealed)
Inks Pigment-based, fade-resistant
Origin Printed in Australia

Important note (mariner’s guidance)

This product is ideal for planning, briefing, education, and display. For underway navigation, always carry and consult the latest official hydrographic chart or approved ECDIS and current Notices to Mariners. Kimberley tidal streams and local conditions can change rapidly.
